CSC RX1E - Technical Specifications

Technical Specifications and Performance Parameters
Note: the continuous mileage refers to the distance from continuous riding on a flat road with a fully charged battery and rated
load to the start of the controller undervoltage protection function. In practical use , the continuous mileage will vary with the
road conditions, the number of parking starts, the size of negative number, wind resistance temperature and other factors.
Items ZS8000D-2 Specifications / Parameters
Outline dimension L
× W × H
82.2
×34×47.4in/2090×865×1205mm
Wheelbase
55.5 in/
1400mm
Minimum ground clearance
6in/
150mm
Complete vehicle curb mass
436.5lbs/
198kg
Maximum capacity
331lbs/
150kg
Maximum speed
75mph/
120km/h
Driving range (working condition method / isokinetic
method)
112 miles
– 62 miles/180km-100km
Motor specification and model
96V / 8KW water cooled motor
, 204YC9637421NA
Peak power
18.5kW
Maximum torque
530N.m
Energy consumption rate (working condition method
/ isokinetic method)
42Wh/km,75Wh/km
Controller
96V
48G sine wave
Battery Specification
Lithium battery 96V64Ah
Undervoltage protection
82V
Overcurrent protection
210A
Charger
External charger AC220V, output current 15A
Charging time
6h
Braking system
ABS, front: disc; Rear: disc
Transmission mode
Belt drive
T
ire size/Air pressure
Front T
ire 100/80-17M/C, 250kpa; Rear Tire 120/80-17M/C, 250kPa
. 35 .
Specifications
