CSI-1 Instruction Manual14
Other Terminals
OPEN / STOP / CLOSE Terminals
The O/S/C facility can be used for an external
push button switch to operate the opener. The
switch must have voltage free normally open
contacts.
Introduction and Application
1. The O/S/C interfaces available.
Add a new O/S/C button to open or close
the door.
2. Flash Light function.
There are corresponding interfaces for this
function and provide 24V-35V flash light
voltage. Connect the flash light with DC
24V-28V, currents<100mA. When use AC
220V power flash lights, please match an
adapter, and wiring as required.
