CSI-1 Instruction Manual8
Mount Wall & Door Bracket
1. Wall Bracket - Close the garage door and measure
the garage door width at the top and mark the
centre. Locate and mount the wall bracket 2cm-
15cm above the door on the inside wall.
(Depend on the actual installation space).
2. Door Bracket – Fix the door bracket to a structural
part of the door as close to the top edge as
possible.
Attach Opener to Track
1. Attach the opener head to the steel track. Assembly the 2 “U” Hanging brackets with 6mm
nuts supplied.
2. Attach the click bracket to the opener and track.
