Chapter 3. LCD Operation
37
November 2001
3.4.5 Data Port Parameter Detail The following shows the setup
screens under the Data Port Parameter Screen.
DATA PORT PARAMETER
<
D
A
T
A
P
O
R
T
>
P
A
R
A
M
E
T
E
R
Press ENTER
R
S
5
3
0
R
E
C
O
N
6
4
2
5
6
K
b
p
s
The first line shows the data port interface type, clock mode, and the
channel's multiplier value (56K or 64K). The second line shows the
channel’s bandwidth used. In the above display, the data port is using an
RS530 interface, clock mode set to E1 Recovery, 64k multiplier and
256Kbps bandwidth (4-64K timeslots). The interface type is automatically
displayed from the identity of the installed module. The only exceptions are
with NRZ/BNC installed or for RS-449. The display will show that an X21
module is installed instead of NRZ and RS-449 uses an adapter cable on
an RS-530 module.
Pressing ENTER from this display will enable editing of the Data Port
parameters.
