CTC Union IGS+803SM-8PH User Manual

11
Panels
No.
Description
1
UTP RJ-45 ports
2
Fiber optic SFP slots
3
Console port (RJ-45 to DB-9)
4
Power, Ring, CPU ACT, Fault LED indicators
5
LAN & PoE LED indicators
6
Fiber LED indicators
7
Terminal block
8
Earth grounding connection
Figure 1. Front Panel
8
7
1
6
4
2
5
7
Figure 2. Top Panel
3
8

CTC Union IGS+803SM-8PH Specifications

General

Brand	CTC Union
Model	IGS+803SM-8PH
Category	Switch
Language	English
