LED Indicators
LED
Color
Status
Definition
PWR1
PWR2
Green
On
Power is connected and active at the
PWR1/PWR2 input terminal
connection.
Off
PWR1/PWR2 is not connected.
Fault
Amber
On
When one or more of the
programmable alarm conditions is
active.
Off
Normal operation without faults.
Alarm conditions are all disabled.
CPU ACT
Green
On
During normal use, this LED will be
lit, indicating a healthy condition of
the running CPU.
Ring
Master
Yellow
On
Lit when this unit is the 'master' in a
fiber ring and all units are
configured for u-Ring or ERPS
(Ethernet Ring Protection Switching
or G.8032).
LAN
LINK/ACT
Green
On
The connected LAN speed is
10/100M.
Blinking
Blinking when there is Ethernet
traffic.
Amber
On
The connected LAN speed is 1000M.
Blinking
Blinking when there is Ethernet
traffic.
FIBER
LINK/ACT
Green
On
The fiber link is up.
Blinking
Blinking when there is data traffic.
PoE
Green
On
The respective LAN port has
successfully negotiated PoE and is
supplying output power to the
remote connected PD.
Blinking
One of the PoE faults (overload,
short circuit, port failure at startup)
occurs.
Off
PD is not connected or output
power is not provided.
