CTM HS-268 - Page 22

Service manual
20
Battery Indicator Instructions
Silicon Button Panel - Battery Indicator
(Total 5 LED lights)
Touch Panel-Battery Indicator
(Total 6 LED lights)
After turning on the main power switch, the scooter battery indicator should be checked :
Number
of lights
LED - 5
lights
LED - 4
lights
LED - 3
lights
LED - 2
lights
LED - 1
lights
≥ 24.6V
<24.6v
<24.1v
<23.7v
<23.4v
≥ 27.4v
<27.4v
<24.1v
Battery power may be
insufficient for folding
or unfolding
Riding is not
recommended, and
battery should be
charged immediately
<23.7v
<23.4v
Lead-acid
battery
Lithium
battery
Remarks
Number
of lights
LED - 6
lights
LED - 5
lights
LED - 4
lights
LED - 3
lights
LED - 2
lights
≥ 27.4v
<26.6v
<25.7v
<24.8v
<24.0
≥ 27.4v
<26.6V
<25.7v
Battery may be
insufficient for folding
/ unfolding
Riding is not
recommended, and
battery should be
charged immediately
<24.8v
<24.0v
LED - 1
lights
Constant lit up
Self-Diagnostic
Warning Light
Lead-acid
battery
Lithium
battery
Remarks
Battery circuit diagram
•Lithium battery - circuit diagram •Lead-acid battery - circuit diagram
