33
SERVICE - 4
Front Wheel Repair :
•Before taking the wheel off, lift the scooter and place a support under the
axle to hold the scooter when the wheel has been taken off.
•When replacing the wheel make sure the sleeve is in the middle so the
wheel will go on properly.
1.Rotate the wheel to find the notch on the wheel cap
2.Insert a flat screwdriver into the notch and
3.Lift the wheel cap off to expose the hub
4.Remove the hexagonal headed bolt (#12) and washer in the center of the axle
5.Take the wheel off the axle.
※After the replacement of parts or re-installation, please follow the exact reverse sequence
for reassembly.
250+-25kgf-cm
