STANDARD ACCESSORIES VESA MOUNT INSTALLATION
1. Contact a professional for assistance when mounting the CTOUCH interactive display.
CTOUCH is not responsible for any damage to the product or injury to yourself, if you mount the
CTOUCH interactive display on your own.
2. Do not mount the CTOUCH interactive display while the CTOUCH interactive display is turned on.
It may cause personal injury due to electric shock.
3. Use standard M8 x 25mm screws (4 pieces) to mount the CTOUCH interactive display.
Warning!
•
Always be sure to ask a qualified technician to carry out set up. Incorrect fitting may cause
equipment to fall, resulting in injury and product damage. Any damage resulting from not having
a professional installer mount your unit will void your warranty.
•
When any optional accessories or brackets are used, always ensure that the instructions
provided are followed fully.
•
Do not mount the unit directly below ceiling lights (such as spotlights or halogen lights) which
typically give off high heat.
•
Take care when fixing wall brackets to the wall. Wall mounted equipment shall not be grounded
by metal within the wall. Always ensure that there are no electrical cables or pipes in the wall
before hanging bracket.
600mm (65")
400mm (55")
800mm (75"/86")
400mm (55"/65")
600mm (75"/86")
Depth of screw:
Minimum 22 mm
Maximum 25 mm
Screw for fixing the CTOUCH interactive
display onto the wall-hanging bracket.
(View from the side)
Unpacking
The following items are included in your product box.
CTOUCH interactive display
HDMI Cable
Remote Control
USB Cable USB-C cable
2 CTOUCH pens
Quick Start Guide
AC Power Cord
Warranty Card
UK AC Power Cord
Welcome Letter
Note: the illustrations may differ slightly from the items shipped with your products.
