Cub Cadet 7252 Parts Manual

-11-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
1 603-0671 Shaft Assembly, Brake .............. 1
2 603-0672 Shaft Assembly, Forward .......... 1
3 603-0673A Link Assembly, Pedal ................ 1
4 603-0674A Plate, Bearing ............................ 1
5 603-0678 Link Assembly, Brake LH .......... 1
6 603-0679A Link Assembly, Parking Brake .. 1
7 603-0680 Link Assembly, Brake RH ......... 1
8 603-0749 Shaft Assembly, Differential ...... 1
9 603-0770 Link, PTO Select ....................... 1
10 603-0774 Link, HI-LO Shift ........................ 1
11 703-3152 Bracket, Reverse Switch ........... 1
12 703-3541 Bracket, Differential Pivot .......... 1
13 703-3571 Handle, PTO ............................. 1
14 703-3575 Link, Differential Pivot ............... 1
15 703-3582 Bracket, Diff. Actuator Mtg. ....... 1
16 703-4099 Bracket, Reverse Switch ........... 1
17 710-0599 Screw, Hex Wash Hd Tapp .......
1/4-20 x .5
2
18 710-0642 Screw, Hex Wash Hd Tapp .......
1/4-20 x .75
4
19 710-1260A Screw, Hex Wash Hd Tapp .......
5/16-18 x .75
12
20 710-0654A Screw, Hex Wash Hd Tapp .......
3/8-16 x 1.0
2
21 711-0415 Pin, Clevis, 3/8 x 1.75 ............... 1
22 711-0723A Ferrule, 3/8-24 x .375 Dia. Hdn 3
23 711-0832 Ferrule, 3/8-24 x .375 Dia. Hdn 1
24 711-1362 Ferrule, Brake ........................... 3
25 711-3397 Ferrule, 3/8-24 x .37 .................. 1
26 712-0239 Nut, Hex Lock, 1/2-20 ............... 3
27 712-0379 Nut, Hex Flange Lock, 3/8-24 ... 1
28 712-0431 Nut, Hex Flange Lock, 3/8-16 ... 2
29 712-0711 Nut, Hex Jam, 3/8-24 ................ 2
30 712-3027 Nut, Hex Flange Lock, 1/4-20 ... 3
31 712-3077 Nut, Hex, M8 x 1.25 GR8.8 ....... 2
32 713-3000 Link, Chain ................................ 1
33 714-0104 Pin, Internal Cotter .................... 13
34 714-0147 Pin, Internal Cotter .................... 2
35 714-3020 Pin, Internal Cotter .................... 1
36 725-3164A Switch, Plunger ......................... 1
37 725-3191A Switch, Plunger ......................... 1
38 727-04033 Cylinder, Damper ...................... 1
39 731-3296 Pedal, Brake .............................. 1
40 731-3299A Pedal, Forward/Reverse ........... 1
41 731-3320 Pedal, Differential ...................... 1
42 731-3321 Grip, Handle .............................. 1
43 732-0324 Spring, Compression ................. 2
44 732-0756A Spring, Torsion .......................... 1
45 732-0859 Spring, Rev/No Cut ................... 1
46 732-3065 Spring, Compression ................. 1
47 732-3117 Spring, Switch Actuator ............. 1
48 732-3118 Spring, Extension ...................... 1
49 736-0173 Washer, Flat, .28 x .74 x .063 ... 3
50 736-0185 Washer, Flat, .375 x .738 x .063 4
51 736-0232 Washer, Wave, .53 x .78 x .013 2
52 736-3019 Washer, Flat, .53 x .1.06 x .134 3
53 736-3069 Washer, Flat, .53 x .875 x .15 ... 2
54 738-0509 Screw, Shoulder, .50 x 1.825 .... 2
55 738-0533 Screw, Shoulder, .498 x 1.635 1
56 738-0689 Screw, Shoulder ........................
1/2 x .180: 3/8-24
1
57 741-0491 Bearing, Nylon. .50 ID x .341 .... 4
58 741-0598 Bearing, Hex Flange, .752 ID .... 2
59 741-3073 Bearing, Flange, .375 x .58 x .25 2
60 741-3074 Bearing, Flange..........................
.626 x .938 x .344
2
61 741-3084 Bearing, Flange..........................
.751 x 1.125 x .375
2
62 747-3396 Rod, Hydro Control ................... 1
63 747-3399 Rod, Brake, LH .......................... 1
64 747-3400 Rod, Brake, RH ......................... 1
65 747-3414 Rod, PTO Control ...................... 1
66 747-3428 Rod, Diff. Lock Control .............. 1
67 747-3429 Rod, HI-LO Control ................... 1
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
CONTROLS
