Cub Cadet 7252 Parts Manual

-15-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
TBD
737-3025
737-3062
737-3035
759-3958
Transmission Ass’y., Includes
Ref. Nos.
Transmission Oil, 1 Qt.
Transmission Oil, 1 Gal.
Transmission Oil, 5 Gal.
Sealant, Loctite
®
Black, 5.3 oz.
1
6.5 gl.
AR
1 603-0688A Arm, Hydro Control ................... 1
2 603-0712A Bracket, Transmission Mtg. RH 1
3 603-0713A Bracket, Transmission Mtg. RH 1
4 619-3059 Cover, Transmission Housing .. 1
5 703-3577 Plate, Feedback ....................... 1
6 703-3715 Baffle, Oil .................................. 1
7 703-05041 Arm, Neutral RH ....................... 1
8 703-05042 Arm, Neutral LH ........................ 1
9 710-0294 Screw, Hex Cap, ......................
1/4-20 x .375 GR5
4
10 710-0591 Screw, Hex Cap Lock, ..............
3.8-24 x 1.0 GR5
1
11 710-0833 Screw, Hex Cap, ......................
5/16-18 x 5.25 GR5
4
12 710-1633 Screw, Plug, M14 x 1.5 x .827 .. 1
13 710-1853 Screw, Hex Special Set, ...........
5/16-18 x .625
1
14 710-3005 Screw, Hex Cap, ......................
3/8-16 x 1.25 GR5
4
15 710-3013 Screw, Hex Cap, ......................
1/4-20 x .5 GR5
2
16 710-3032 Screw, Hex Cap, ......................
1/2-13 x 1.25 GR5
6
17 710-3120 Screw, Hex Cap Lock , .............
3/8-16 x 1.5 GR5
9
18 710-3262 Screw, Low Hd. Cap, ................
3/8-16 x .75
2
19 711-1355 Shaft, Rock ............................... 1
20 712-0431 Nut, Hex Flange Lock, 3/8-16 ... 2
21 716-0111 Ring, Retaining ......................... 1
22 716-0195 Ring, Retaining ......................... 1
23 717-3507 Pump, Hydrostatic Transmission 1
24 718-3131 Pump, Auxiliary Hydraulic ......... 1
25 719-3166 Arm, Upper Hitch RH ................ 1
26 719-3167 Arm, Upper Hitch LH ................ 1
27 721-0501 O-Ring, 2.987 ID x .103 Dia ..... 1
28 721-0510 Seal, Oil, 1.5 x 2.0 x .25 ........... 2
29 723-0405 Filter, Oil - Hydraulic System .... 1
30 723-3014 Filter, Oil - Hydro Pump ............ 1
31 723-3021 Breather, Transmission ............ 1
32 725-3272 Sensor, RPM ............................ 1
33 727-3012 Fitting, 90° ................................ 2
34 727-3176 Tube, Auxiliary Pump Suction .. 1
35 727-3181 Tube, Hydro Suction ................. 1
36 731-04018 Grommet ................................... 1
37 732-1162 Spring, Extension ..................... 1
38 736-3052 Washer, Flat, .406 x 1.0 x .105 . 2
39 737-0146 Fitting, Grease .......................... 1
40 737-0349 Plug, Fitting ............................... 2
41 737-3105 Fitting, Filter Nipple ................... 1
42 737-3108 Fitting, 90° ................................ 1
43 737-3111 Fitting, 90° ................................ 1
44 737-3112 Fitting, Straight ......................... 1
45 737-3113 Fitting, Straight ......................... 2
46 738-0108 Screw, Shoulder, .498 Dia x 1.45 1
47 738-0430 Screw, Shoulder, .50 Dia x .685 1
48 738-04001 Screw, Shoulder, ......................
.625 x .18: 1/2-13
4
49 741-1110 Bearing, Sleeve, .......................
1.52 x 1.75 x 1.0
2
50 750-1208 Spacer, .40 x 1.0 x 3.9 .............. 4
51 750-1239 Spacer, 1.52 x 2.25 x .188 ........ 2
52 737-04018 Dipstick ..................................... 1
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
2WD TRANSMISSION
