Cub Cadet 7252 Parts Manual

-23-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
† 629-3063 Harness, Engine ................ 1
1 703-3521A Plate, Engine Mtg. ............. 1
2 703-3684 Bracket, Filler Neck ........... 1
3 703-3688
777S30632
Bracket, Radiator Mtg. RH .
Graphic, Warning ...........
1
1
4 703-3689
777S30632
Bracket, Radiator Mtg. LH .
Graphic, Warning ...........
1
1
5 703-3691
777S30631
777S30633
Plate, Radiator Baffle .........
Graphic, Fan Warning ....
Graphic, Warning ...........
1
1
1
6 703-3692 Bracket, Radiator Mtg. ....... 1
7 703-3722 Bracket, Ovrflw Bottle Mtg. 1
8 703-05140 Plate, Baffle RH ................. 1
9 703-05141 Plate, Baffle LH .................. 1
10 703-4063 Shield, Heat ....................... 1
11 710-0357 Screw, Square Hd. Set, .....
3/8-16
2
12 710-0514 Screw, Hex Cap, ................
3/8-16 x 1.0 GR5
4
13 710-0597 Screw, Hex Cap, ................
1/4-20 x 1.0 GR5
2
14 710-0599 Screw, Hex Wash Hd Tapp
1/4-20 x .5
4
15 710-0607 Screw, Hex Wash Hd Tapp
5/16-18 x .5
12
16 710-0623 Screw, Hex Wash Hd Tapp
3/8-16 x .75
4
17 710-1260A Screw, Hex Wash Hd Tapp
5/16-18 x .75
8
18 710-1376 Screw, Hex Cap, M8-20 x 16 1
19 710-3015 Screw, Hex Cap, ................
1/4-20 x .75 GR5
9
20 710-3208 Screw, Hex Cap, ................
M10 x 1.5 x 25
6
21 712-0324 Nut, Hex Nylon Insert Lock
1/4-20 GR8
11
22 712-0431 Nut, Hx Flnge Lock, 3/8-16 4
23 717-3498 Shaft, Drive ........................ 1
24 718-3132 Cooler, Oil .......................... 1
25 722-3022 Tape, Foam, .625 wide ...... 42in.
26 723-3061 Seal, Heat Baffle ................ 96in.
27 725-3282 Wire, Battery Neg. ............. 1
28 725-3289 Wire, Battery Pos. .............. 1
29 726-0154 Tie, Cable - Push Mount .... 4
30 726-0205 Clamp, Hose ...................... 7
31 726-0476 Clamp, Hose - Adjustable .. 1
32 726-0480 Clamp, Hose ...................... ‘ 6
33 731-04018 Grommet ............................ 2
34 731-3364 Shroud, Fan ....................... 1
35 735-0226 Grommet ............................ 2
36 736-0173 Washer, Flat, .....................
.28 x .74 x .063
7
37 746-04015 Cable, Choke Control ........ 1
38 751-3130 Fuel Line 5/16 ID ............... 94in.
39 751-3166 Muffler ................................ 1
40 751-3177 Hose, Filler to Radiator ...... 1
41 751-3185 Radiator ............................. 1
42 751-3187 Hose, Lower Radiator ........ 1
43 751-3189 Hose, Engine to Filler Neck 1
44 751-3190 Filler Neck, Remote Radiator 1
45 751-3192 Cap, Remote Filler ............. 1
46 751-3193 Screen, Radiator ................ 1
47 751-3203 Hose, Intake Air ................. 1
48 KM-49040-2065 Pump, Fuel ........................ 1
49 KM-49019-1055 Filter, Fuel .......................... 1
50 KM-11060-2467 Gasket, Exhaust ................ 2
51 KM-461F0800 Washer, Spring .................. 4
52 KM-317R0800 Nut, Hex ............................. 4
53 KM-92038-2101 Key, Crankshaft ................. 1
54 KM-43078-2055 Bottle, Over Flow ............... 1
55 KM-39062-2086 Tube ................................... 1
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
ENGINE AND DRIVE SHAFT
† Not Shown
