-25-

REF.

NO.

PART

NUMBER DESCRIPTION QTY.

1 KM-11004-2142 Gasket, Head .................................. 2

2 KM-11008-2145 Head, Cylinder ................................ 1

3 KM-11008-2146 Head, Cylinder ................................ 1

4 KM-11022-2072 Cover, Rocker ................................. 1

5 KM-11022-2073 Cover, Rocker ................................. 1

6 KM-11060-2466 Gasket, Breather ............................ 1

7 KM-11060-2470 Gasket, Rocker Cover .................... 2

8 KM-13271-2105 Plate, Breather ................................ 2

9 KM-14091-2064 Cover, Breather .............................. 1

10 KM-16126-2225 Valve, Breather ............................... 2

11 KM-49015-6239 Cover, Crankcase ........................... 1

12 KM-49120-6127 Crankcase, .....................................

(Includes Ref. Nos. 13 and 19)

13 KM-59071-2079 Joint ................................................ 1

14 KM-92009-2308 Screw .............................................. 2

15 KM-92043-1037 Pin .................................................. 6

16 KM-92049-2242 Seal, Oil .......................................... 1

17 KM-92049-2243 Seal, Oil .......................................... 1

18 KM-92093-2086 Seal ................................................ 1

19 KM-92141-2118 Bearing, Plane ................................ 1

20 KM-92141-2119 Bearing, Plane ................................ 1

21 KM-92151-2158 Bolt, M8 x 55 ................................... 4

22 KM-92151-2159 Bolt, M8 x 80 ................................... 8

23 KM-92170-2002 Clamp ............................................. 2

24 KM-92191-2105 Tube ............................................... 1

25 KM-130G0630 Bolt, Flange .................................... 8

26 KM-130G0830 Bolt, Flange .................................... 4

27 KM-130G0845 Bolt, Flange .................................... 6

28 KM-130G0860 Bolt, Flange .................................... 4

29 KM-172G0822 Bolt, Stud ........................................ 4

30 KM-670B2011 O-Ring ............................................ 3

CYLINDER HEADS AND CRANKCASE
