Cub Cadet 7252 Parts Manual

-37-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
1 603-0719 0637 Hinge Assembly, Hood .................. 1
2 603-0784 0637 Bracket, Side Panel Mtg. RH ......... 1
3 603-0785 0637 Bracket, Side Panel Mtg. LH .......... 1
4 603-0924 0637 Bracket, Side Panel Mtg. RH Rear 1
5 603-0925 0637 Bracket, Side Panel Mtg. LH Rear 1
6 625-0052
725-3161A
Headlight Assembly .......................
Bulb, Headlight ...........................
1
4
7 703-3394 Screen, Intake ................................ 1
8 703-3712 Shield, Upper Heat ........................ 1
9 703-3764 Bracket, Panel Mtg. ....................... 1
10 703-3765 Shield, Lower Heat ........................ 1
11 710-0473 Screw, Truss Hd, 10-24 x .5 .......... 6
12 710-0599 Screw, Hex Wash Hd Tapp ...........
1/4-20 x .5
14
13 710-0751 Screw, Hex Cap, 1/4-20 x .62 GR5 4
14 710-3170 Stud, Cylinder, 5/16-18 Thrd .......... 4
15 712-0272 Nut, Hex Sems, 10-24 ................... 6
16 712-0324 Nut, Hex Nylon Insert Lock, 1/4-20 4
17 712-0431 Nut, Hex Flange Lock, 3/8-16 ........ 2
18 712-3004A Nut, Hex Flange Lock, 5/16-18 ...... 4
19 726-3056 Latch, 1/4 Turn Panel .................... 4
20 727-3194 Cylinder, Gas Spring ...................... 2
21 731-3277
777D05419
777D05420
777D05390
Hood ..............................................
Graphic, Hood RH ......................
Graphic, Hood LH .......................
Graphic, Model 7252 ..................
1
1
1
2
22 731-3278 Panel, Side RH .............................. 1
23 731-3279 Panel, Side LH ............................... 1
24 732-0936 Clip, Spring .................................... 4
25 732-0937 Spring, Compression ..................... 4
26 736-0272 Washer, Flat, .510 x .1.0 x .060 ..... 2
27 738-0380 Screw, Shoulder, .5 x .27 Lg 3/8-16 2
28 726-04010 Clip, Retaining ............................... 1
HOOD, GRILL AND SIDE PANELS
