Page #45 background image
-45-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0813 Pivot Bracket Assembly ............... 1
2 603-0862 Valve Handle Assembly .............. 1
3 703-3598-0637 Loader Valve Mount Bracket ....... 1
4 703-3972-0637 Fitting Mount Plate ...................... 1
5 703-3973-0637 Rear Fitting Mount Plate ............. 1
6 710-0501 Hex Screw, 1/4-20, 2.00, Gr5 ..... 2
7 710-0599 Hex Wash. Hd. Tapp Screw ........
1/4-20 x .50
2
8 710-0604A Hex Wash. Hd. Tapp Screw ........
5/16-18 x .625
2
9 710-1260A Hex Wash. Hd. Tapp Screw ........
5/16-18 x .75
4
10 711-1611 Valve Pivot Shaft ........................ 1
11 711-1624 Valve Spool Link ......................... 1
12 711-1637 Ball Joint Pivot Stud .................... 1
13 711-1642 Clevis Pin, .199 x .8125 .............. 1
14 712-0256 Jam Nut, 5/16-24, Gr2 ................ 2
15 712-0324 Hex Lock Nut, 1/4-20, Gr8, Nylon 2
16 713-3000 Chain Link ................................... 1
17 714-0104 Internal Cotter Pin ....................... 1
18 716-0865 Snap Ring, .5 .............................. 2
19 718-3138
759-3964
759-3965
759-3966
Auxiliary Hydraulic Pump ............
Pin, Dowel ................................
Bolt, Mounting ..........................
Coupler, Splined ......................
1
2
4
1
20 718-3140 Loader Control Valve .................. 1
21 723-0488 Ball Joint, .3125 Id x 5/16-24 ...... 1
22 727-3012 Fitting, 90° 6-6 Orb ..................... 2
23 727-3206 Tube, Tandum Pump Suction ..... 1
24 727-3210 Tube, Hydraulic - Bucket Rollback 1
25 727-3211 Tube, Hydraulic - Bucket Dump .. 1
26 727-3212 Tube, Hydraulic - Boom Lift ........ 1
27 727-3213 Tube, Hydraulic - Boom Lower ... 1
28 727-3224 Coupling, Male Hydraulic, 3/8-18 2
29 727-3225 Coupling, Female Hydr. 3/8-18 ... 2
30 727-3226 Tube, Auxiliary Pump Pressure .. 1
31 727-3227 Tube, Valve Pressure ................. 1
32 727-3228 Tube, Valve Return ..................... 1
33 727-3229 Tube, Valve Return ..................... 1
34 727-3261 Plug, Hydraulic Coupler - Male ... 2
35 727-3262 Plug, Hydraulic Coupler - Female 2
36 731-3353 Knob, 1.625 Dia x 3/8-16 Thd 1
37 731-3374 Washer, Indicator - Red .............. 1
38 731-3375 Washer, Indicator - Yellow .......... 1
39 731-3376 Washer, Indicator - Green ........... 1
40 731-3377 Washer, Indicator - Blue ............. 1
41 735-0696 Joystick Boot ............................... 1
42 737-3111 Fitting, 90° -8 Orb ...................... 1
43 737-3112 Fitting, Straight -8 Orb ................. 2
44 737-3113 Fitting, Straight ............................ 2
45 737-3125 Fitting, Straight - 6 Orb ................ 2
46 737-3129 Fitting, Bulkhead 3/4-16 x 3/8-18 4
47 737-3130 Fitting, Bulkhead 3/4-16 x 3/4-16 2
48 750-0845 Spacer, .34 ID x .5 OD x .31 ....... 1
AUXILIARY HYDRAULIC LOADER VALVE
(IF EQUIPPED)
