-9-

REF.

NO.

PART

NUMBER CODE DESCRIPTION QTY.

1 603-0711 Tab Assembly, Throttle .................. 1

2 629-3061 Wire Harness, Dash ....................... 1

3 631-0076 Boot, Steering Shaft ....................... 1

4 631-04007A Dash .............................................. 1

5 703-05132 Plate, Throttle Mtg. ........................ 1

6 710-0604A Screw, Hex Wash. Hd. Tapp .........

5/16-18 x .625

7 710-0924 Screw, Pan Hd., 1/4-20 x .75 ......... 4

8 710-3013 Screw, Hex Cap, 1/4-20 x .5 GR5 . 6

9 712-0237 Nut, Hex Lock, 5/16-24 .................. 1

10 712-0292 Nut, Speed, 1/4-20 ......................... 2

11 712-0116 Nut, Hex Insert Jam Lock, 3/8-24 1

12 723-3013 Washer, Friction, .515 x 1.5 x .12 .. 1

13 725-2017 Plug ................................................ 1

14 725-3265

725-3285

735-0688

Panel, Instrument ...........................

Bulb ............................................

Plug ............................................

15 725-3274 Switch, Headlight ........................... 1

16 725-3276 Switch, PTO ................................... 1

17 725-3277 Switch, Ignition ............................... 1

18 725-3279 Switch, Hazard ............................... 1

19 731-3209 Steering Wheel, Soft Grip .............. 1

20 731-3210 Cover, Steering Wheel ................... 1

21 731-3298 Handle, Throttle ............................. 1

22 731-3344 Panel, Dash Insert ......................... 1

23 736-0242 Washer, Belleville, .34 x .872 x .06 1

24 736-0329 Washer, Lock, 1/4 .......................... 3

25 736-0112 Washer, Belleville, .531 x 1.62 x .045 2

26 736-3052 Washer, Flat, .406 x 1.0 x .105 ...... 1

27 746-3086A Cable, Throttle ............................... 1

28 759-3950 Key Set, Ingition ............................. 1

DASH PANEL AND STEERING WHEEL

Cub Cadet 7252 Parts Manual
