Camshaft & Gears Plate A
C1LH
Item Part No. References Qty. Description Notes
1
153-7984 1 GEAR - IDLER/OIL PUMP
2
Ñ
153-7984 1 GEAR
3 (030509018) 3 DOWEL
4 154-1679 1 SPRING
5
Ñ
153-7984 1 VANE
6 154-1677 3 BUSH
7 153-7985 1 WASHER
8 (120026610) 1 CAMSHAFT ASSEMBLY
9
Ñ
(120026610) 1 CAMSHAFT
10 183-3606 1 SPACER
11 183-3645 1 CAMSHAFT GEAR
12 (034100508) 1 WOODRUFF KEY
13 (040109059) 1 BALL BEARING
14 217-7174 1 TAPPET
15 153-7990 1 PLATE
16 (011310612) 1 SCREW
17 153-7992 1 SCREW
