Cub Cadet 7284 - Servicing the Electrical System

Page 33
Fuel Injection Pump Plate A
D1AH
Item Part No. References Qty. Description Notes
1 (131017940) 1 FUEL INJECTION PUMP
2
Ñ
(131017940) 1 FUEL INJECTION PUMP
3 205-4728 1 CONNECTION
4 205-4726 1 BOLT
5 205-4727 1 GASKET
6 205-4727 1 GASKET
7 (011310620) 2 SCREW
8 153-5960 2 NUT
9
˙
1 SHIM
Ñ
(SERVICE OPTION)
10 238-1210 1 SOLENOID
11 153-6412 1 WASHER
Service Options
9 153-6385
˚
(+)0.20MM 1 SHIM
9 161-1432
˚
(+)0.28MM 1 SHIM
9 161-1433
˚
(+)0.38MM 1 SHIM
9 161-1435
˚
(+)0.90MM 1 SHIM
9 161-1434
˚
(+)0.49MM 1 SHIM
