Page 37
Atomisers Plate A
D1AH
Item Part No. References Qty. Description Notes
1
231-7739 1 ATOMISER LEAK-OFF PIPE
2 (067200078) 1 CLIP
3
(068209026) 1 FUEL INJ PUMP RETURN PIPE
4 (067200078) 1 CLIP
5 232-0290 1 CONNECTOR
6 153-6415 2 WASHER
7 (131406470) 3 ATOMISER
8
Ñ
(131406470) 1 BODY
9 232-0793 1 WASHER
10 154-2716 3 GASKET
