Cub Cadet 7284 Engine Parts Manual

Page 61
Starter Group Plate B
K1PK
Item Part No. References Qty. Description Notes
1 138-6754
é
138-7454 1 STARTERMOTOR (A) 1.4 KW
2 (010311045) 2 BOLT (B)
3 155-8085 2 NUT
4 154-1399 2 WASHER
5 154-2403 2 WASHER
Footnotes
(A) BREAKDOWN HAS YET TO BE ADVISED.
(B) STARTER MOTOR

Cub Cadet 7284 Specifications

General

Brand	Cub Cadet
Model	7284
Category	Tractor
Language	English
