Cub Cadet 7284 Engine Parts Manual

Parts Index
Page 85
Description Part No. Page
ADAPTOR 217-5792 71
ADJUSTING SCREW 153-5587 21
AIR INTAKE PIPE 231-3013 73
ALTERNATOR 183-4029 65
ANTI-TAMPER CAP 139-5511 27
211-7739 29
217-7115 29
ARM 154-1401 25
154-1637 25
ATOMISER (131406470) 37
ATOMISER LEAK-OFF
PIPE
231-7739 37
BACKPLATE (TPN768) 59
BALL BEARING (040109059) 31
153-5390 11
BEARING (042303015) 11
BEARING CAP 231-2801 17
231-2802 17
231-2803 17
BIG END SHELL BEAR-
ING
231-8814 15, 15
BLANKING PLUG 217-7381 41
BOLT (010310865) 69
(010311045) 61
(010810845) 17
153-6881 51
191-9296 29
205-4726 33
212-0745 29
BOLT ASSEMBLY 217-7111 29
BRACKET 183-4033 65
BREATHER VALVE 217-5859 73
BUSH 153-5536 15
154-1677 31
231-8817 11
CABLE 155-8075 39
CAMSHAFT ASSEMBLY (120026610) 31
CAMSHAFT GEAR 183-3645 31
CAP 153-5573 19
CIRCLIP (036500021) 13, 13
(036800005) 25
(036800006) 25
153-6851 53
212-0747 29
CLIP (067200078) 37, 37
154-1824 41, 41
COLLAR 153-6850 53
CONNECTION 153-6879 49
197-8555 81
205-4728 33
CONNECTOR 183-4037 81
231-2841 39
232-0290 37
CON ROD BOLT 153-5537 15
CONROD KIT 231-3870 15
CON ROD NUT (020109075) 15
CORE PLUG (064400010) 11, 71
COTTER 153-5556 19
COVER 153-6848 53
CRANKSHAFT GEAR 153-5517 17
CRANKSHAFT KIT 231-2799 17
