2 Installation and Removal of Engine Parts
16
19. Remove the cover.
20. Remove the column boot.
21. Remove the rear panels PH and LH.
22. Remove the meter panel.
• Disconnect the connectors for harness E and
harness B.
• Remove the tachometer.
Cover
GZ3W21-020
Columnboot
Panel
GZ3W21-021
Rearpanel
Panel
GZ3W21-022
Meterpanel
GZ3W21-023
