Installation and Removal of Engine Parts 2
15
15. Loosen the drain plug and drain the transmission
oil.
Capacity
Manual transmission specification :
29 L {7.7 gal}
HST specification :
32 L {8.5 gal}
16. Remove the return pipe from the oil pump II and I.
17. Remove the power steering hose.
18. Remove the pressure pipe.
CAUTION
Take cautions not to drop the O-ring and gasket.
Drainplug
GZ3W21-016
OilpumpII
Returnpipe
OilpumpI
GZ3W21-017
Powersteeringhose
GZ3W21-018
Pressurepipe
GZ3W21-019
