Brake Assembly
- Parts List for Figure 10
Ref.
No. Part No. Description Qty.
1 741-0598 Hex Flange Bearing, .752 ID 2
2 00011459 Flat Washer, 1/2 2
3 01000371 Hex Cap Screw, 3/8-16 x 3-1/4 1
4 00012382 Hex Cap Screw, 5/16-18 x 1-1/2 2
5 00012152 LockNut, 1/4-20, Nylon Insert 1
6 00022560 Flange Lock Hex Nut, 3/8-16 1
7 00027279 Nylock Nut, 7/16-14 2
8 00071691 Spacer, Control Rod 1
9 01000393 Washer, .469 ID x .875 OD x .105 4
10 01000635 Hex Flange Lock Nut, 5/16-18 4
11 01000897 Self Tapping Screw, 1/4-20 x 1.00 1
12 01002751 Spacer, .39 x .63 x 1.75 1
13 01002771 Cotter Pin, .072 x 1.12 Lg 4
14 01003468 Spacer, .375 x .50 x .75 Lg 1
15 01003595 Brake Handle 1
16 01003574 Neutral Brake Spring 2
17 01003575 Force Brake Spring 2
18 01003716 Parking Brake Grip 1
19 01008600 Socket Head CapScrew, 5/16-18 x 1.50 1
20 01008607 Spacer, .375 OD x .257 ID x .438 1
21 01008886 Brake Rod 1
22 01008889 Parking Brake Mounting Bracket 1
23 01009561 Brake Arm Assembly 1
24 01009566 Brake Bracket 2
25 01009568 Linkage Brake Rod 2
26 01009569 Pivot Brake Shaft 1
27 01009601 Low Pressure Hose 2
28 01009602 Spacer, .76 ID x 1.0 OD x .75 2
29 00013092 HHCS, 5/16-18 x 1.0 1
30 01000629 Screw, TT, 1/4-20, 0.75, Hex Index Washer 1
31 01000723 Flat Washer, .406 ID, 1.0 OD, .105 1
To Next Page
