17
Control Assembly -
Parts List for Figure 16
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 00008495 Capscrew, 3/8-16 x 1-3/4 2 25 01003199 Stop, RH 1
2 00009812 Flat Washer, 5/16 4 26 01003200 Stop, LH 1
3 00011861 HHCS, 3/8-16, 2.25 4 27 01003451 Decal Right Hand Control 1
4 00012168 5/16, Lock Washer 2 28 01003452 Decal, Left Hand Control 1
5 00012226 Grease Fitting, 90° 2 29 01003561 Nut, Hex, Center Lock, M8 4
6 00013092 HHCS, 5/16-18 x 1.0 1 30 01003715 Grip, 1.0 2
7 00013406 Hex, Cap Screw, 5/16-18 x 3/4 4 31 01003947 U-Nut, 3/8-16, .75 2
8 00022560 Hex Nut, 3/8-16, Lock Flange 23 32 01004003 Flat Washer, 5/8 Nylon 4
9 01000372 Carriage Bolt, 3/8-16 x .75 15 33 01004127 HHCS, 3/8-16, 3.00 2
10 01000450 Hex Jam Nut, 3/8-24 4 34 01005851 External Washer, 3/8 2
11 01000451 B/Joint, 3/8-24, Right Hand Female 2 35 01004890 Control Panel, RH 1
12 01000628 Screw, TT, 1/4-20, 0.5, Hex Index Washer 11 36 01006350 Shaft Collar 2
13 01000629 Screw, TT, 1/4-20, 0.75, Hex Index Washer 1 37 01007312 Spacer, .385ID x .625 OD x .50 Lg 2
14 01000635 Nut, Lock, HexFlange, 5/16-18 7 38 01007734 Turnbuckle 2
15 01000643 Carriage Bolt, 3/8-16 x 1 2 39 01008367 B/Joint, 3/8-24, Left Hand Female 2
16 01000960 Belle Washer, .325 x .930 x .045 2 40 01008518 Rod Connector 3/8 OD x 14.25 2
17 01001727 Cylinder Return to Neutral 2 41 01010190 Lapbar, Handle Assembly 2
18 01002511 Nut, 3/8-16, Jam 2 42 01010176 Mounting Handle 2
19 01002986 Nut, 3/8-24, Jam, LH Third 2 43 02000164 Switch Mounting Bracket, Lapbar 2
20 01002988 Screw, Shoulder Control Rod 2 44 02000162 Decal, Left Hand Console 1
21 01003044 Hub Assy, Control LH Bearing 1 45 02000163 Decal , Right Hand Console 1
01004265 Bearings 2 46 02000175 Shaft Control Brake Steering 1
22 01003011 Lever, Safety Switch 2 47 02000178 Side Panel, Control, Right 1
23 01003045 Hub Assy, Control RH Bearing 1 48 02000179 Side Panel, Control, Left 1
01004265 Bearings 2 49 02000340 Cup Holder Assembly 1
24 01004889 Control Panel, LH 1 50 01000443 Screw Button Head, 1/4-20 x .5 1
To Next Page
