27HP Kohler Engine Assembly
- Parts List for Figure 19
Ref
No Part No. Description Qty.
1 00005763 Hex Nut, 7/16-14 1
2 00006129 HHCS, 5/16-18, 1-3/4 4
3 00014602 Round Hd. Machine Screw, 10-32 x 3/4 2
4 00014608 Lock Nut, Nylon Insert, 10-32 2
5 00022560 Flange Lock, Hex Nut, 3/8-16 2
6 00060056 Nut Washer, W/Star, 8-32 2
7 00060078 Grease Fitting, 1/4-28 x 3/16 1
8 01000199 Extension Spring, 1.0 OD x 5.125 1
9 01000302 Shoulder Screw, 7/16-14 1
10 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
11 01000389 Lock Washer, 7/16 2
12 01000635 Hexflange Lock Nut, 5/16-18 4
13 01000721 Machine Screw, 8-32, .375 2
14 01000728 Clip, Heat Shield Cable 1
15 00012169 Flat Washer, 5/16 2
16 01001395 Capscrew, 7/16-20 x 2.50 1
17 01001979 Clutch Brake, 1.125 ID 1
18 01002601 Hex Cap Screw, 3/8-16, .750 1
19 01003269 Flat Washer, 7/16 ID x 1.75 OD x .25 1
20 01008256 Choke Control Cable 1
21 01003273 Throttle Control Cable 1
22 01003283 Oil Drain Hose 1
23 01004004 Control Throttle Knob 2
24 01004081 Flat Pulley with Flanges 1
25 01005006 Engine Idler Arm Casting 1
26 01000811 Screw, #8-32, 0.375 Hxindwsh 2
27 01008623 Straight Exhaust Pipe, Selxsys 1
28 01005104 Pump Drive Pulley 1
29 01005314 Flat Washer, 7/16 ID x 1.75 OD x .25 1
30 01005856 Key, 1/4 x 1/4 x 3 1
31 01006456 Retainer Clutch Assembly, Ogura 1
32 01007015 Belt, 51.2 Lg 1
33 01007598 Engine, 27HP Kohler 1
34 01006566 Muffler Accessory Kohler 1
Note: Engine Oil 10W40 by the Gallon
