23
25HP Kawasaki Engine Assembly
- Parts List for Figure 20
Ref
No Part No. Description Qty.
1 00005763 Hex Nut, 7/16-14 1
2 00006129 HHCS, 5/16-18, 1-3/4 4
3 01000811 Screw, #8-32 x 0.375 2
4 00014602 Round Hd. Machine Screw, 10-32 x 3/4 2
5 00014608 Lock Nut, Nylon Insert, 10-32 2
6 01005856 Key, 1/4 x 1/4 x 3 1
7 00022560 Flange Lock, Hex Nut, 3/8-16 2
8 00060056 Nut Washer, W/Star, 8-32 2
9 00060078 Grease Fitting, 1/4-28 x 3/16 1
10 01000199 Extension Spring, 1.0 OD x 5.125 1
11 01000302 Shoulder Screw, 7/16-14 1
12 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
13 01000389 Lock Washer, 7/16 2
14 01000635 Hexflange Lock Nut, 5/16-18 4
15 01000721 Machine Screw, 8-32, .375 2
16 01000728 Clip, Heat Shield Cable 1
17 00012169 Flat Washer, 5/16 1
18 01001395 Capscrew, 7/16-20 x 2.50 1
19 01001979 Clutch Brake, 1.125 ID 1
20 01002601 Hex Cap Screw, 3/8-16, .750 1
21 01006456 Retainer Clutch Assembly, Ogura 1
22 01003269 Flat Washer, 7/16 ID x 1.75 OD x .25 1
23 01003271 Choke, Control Cable, 43.0 1
24 01003272 Throttle, Control Cable, 39.0 1
25 01003283 Oil Drain Hose 1
26 01008525 25HP Twin Engine, Kawasaki 1
27 01004004 Control Throttle Knob 2
28 01004081 Flat Pulley with Flanges 1
29 01009299 Muffler Accessory, Kawasaki 1
30 01005006 Engine Idler Arm Casting 1
31 01007015 V Belt, A Section x .47.3 1
32 01008623 Muffler Accessory Exhaust Tube 1
33 01005104 Pump Drive Pulley 1
34 01005314 Flat Washer, 7/16 ID x 1.75 OD x .25 1
