25
Electrical Assembly
Kohler
- Parts List for Figure 23
Ref.
No. Part No. Description Qty.
1 00012032 Battery, 12V 225CCA 30 Min 1
2 00012289 Cable, Battery, Red, 36" 1
3 00012470 Tie, Cable, 3/16 x .05 x 7.4" 5
4 00013131 Screw, Hex, Cap, 1/4-20 x .75 2
5 00013258 Boot, 1" OD Rubber Battery-PST, Red 1
6 00014608 Lock Nut, Nylon Insert 1
7 00030906 Screw, Phillips Head, Machine, 10-32 x 5/8 1
8 00032097 Nut, W/Cap, 5/8-32 Ignition 1
9 01000628 Screw, TT, 1/4-20, 0.5, Hex Index Washer 2
10 01001811 Hourmeter, Harness (not shown) 1
11 01002111 Switch, Electric, PTO 1
12 01002766 Lock Nut, 1/4-20 2
13 01003581 Switch, Ignition, 6 Pin 1
14 01003649 Strap, Battery 1
15 01004040 Grommet, .75 ID 1
16 01004078 Cable, Battery Red, 28" 1
17 01005389 Meter, Hour 1
18 01008042 Spring Retainer 1
19 01009905 Bracket, PTO Switch Retainer 1
20 01009995 Mount Bracket, Battery 1
21 02000024 Switch, Safety N.O./N.C. 2
22 02000165 Switch Plunger 1
23 02000592 Harness Assembly (not shown) 1
24 02000349 Bracket, Plunger Switch 1
25 02000348 Clamp, Plunger Switch 1
26 01002251 Relay, 12V 40A 1
