7
60" Fabricated Deck Spindle Assembly
- Parts List for Figure 7
Ref.
No. Part No. Description Qty.
1 01000389 Lock Washer, 7/16 1
2 00008495 Hex Cap Screw, 3/8-16 x 1-1/4 13
3 00011925 Hex Cap Screw, 3/8-16, 4.00 1
4 00012158 Flat Washer, 3/8 12
5 00021925 Caster Spacer 1
6 00022560 Flange Lock Hex Nut, 3/8-16 17
7 00060078 Grease Fitting, 1/4-28 x 3/16 1
8 00083192 Idler Washer 3
9 01000199 Extension Spring, 1.0 x OD x 5.125 1
10 01000302 Shoulder Screw, 7/16-14 1
11 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
12 01000380 Flange Hex Nut, 3/4-16 3
13 01000387 Torsion Idler Spring 1
14 01000392 Flat Washer, .781 ID 2.00 OD, .105 3
15 01000393 Flat Washer, .469 ID, .875 OD, .105 1
16 01005616 V-Pulley, 5.00 OD 3
17 01000643 Carriage Bolt, 3/8-16 x 1 1
18 01000723 Flat Washer, .406 ID, 1.0 OD, .105 4
19 01003245 Spacer, .39 ID x .625 OD x 2.75 1
20 01003532 Aluminum Spindle Assembly 3
21 00005763 Hex Nut, 7/16-14 1
22 01004081 Flat Pulley 1
23 01004101 Idler Pulley, 4.06 OD 1
24 01004118 Shoulder Screw, .50 x .27 Lg., 3/8-16 1
25 01004415 Spacer, .760 ID x 2.00 OD x 1.1 4
26 01005434 Aluminum Spindle Support Plate 3
27 01005203 V-Pulley, 5.774 OD 1
28 01005213 Hex Cap Screw, 3/4-16, 7.00 2
29 01005338 Hi-Lift Blade, 21.0, 0.756 ID 3
30 01003123 Spacer .812 ID x .268 LG 2
31 01005376 V-Belt, A Section x 122.3 1
32 01005377 V-Belt, B Section x 91.2 1
33 01005388 Hex Cap Screw, 3/4-16, 9.00 1
34 01005690 Spring Tension Rod Assembly 1
35 01005737 Idler Arm Assembly, Deck Spindle 1
36 01006181 Idler Arm Assembly, Flat Top Bearing 1
01000308 Bearing Sleeve 2
37 01006382 Decal, Idler Location 1
