Cub Cadet LTX 1040 Illustrated Parts Manual

11
Ref.
Part Number Description
1 747-04121A Battery Hold-Down Rod
2 712-0271 Sems Nut, ⁄-20
3 710-04666 Hex Flange, ⁄-20 x .75
4 925-1707D Battery
5
783-06089-0637 Seat Frame Bracket
6 710-04484 Hex Washer Screw, ⁄-18 x .750
7 738-04058 Shoulder Spacer, .38 x 1.0 x .70
8 710-3005 Hex Screw, ⁄-16 x 1.25
9 783-0349-0637 Battery Tray
10 712-04065 Flange Lock Nut, ⁄-16
11 725-04439 Solenoid
12 710-0653 Hex Washer Screw, ⁄-20 x .375
13 712- 04064 Flange Lock Nut, ⁄-20
14 738-04237A Shoulder Screw, #10-32 x .500
15 725-04363 Interlock Switch
16
683-04469-0637
Lower Frame Assembly
17 756-04208A Engine Pulley
18 736-0322 Flat Washer, .450 x 1.250 x .164
19 936 -0171 Lock Washer, ⁄
20 710-04607 Hex Screw, ⁄-20 x 2.75
21 712-04063 Flange Lock Nut, ⁄-18
22 747-05065 Keeper Rod
Frame, Battery & PTO

Cub Cadet LTX 1040 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	42 inches
Transmission Type	Hydrostatic
Deck Material	Steel
Turning Radius	18 inches
Number of Speeds	Infinite
Cutting Height	1.5 - 4 inches
Number of Blades	2
Front Tire Size	15x6-6
Rear Tire Size	20x8-8
Blade Engagement	Manual
Warranty	3 years limited
Engine Type	Single-cylinder OHV
