SCALE
100%
50%
0%
SLOW
FA
ST
SEAT ADJUSTER
RELEASE
777D10279
Centered on Rear Fender
777D12929
777D12928
777I20310
777D12864
777I23084
777I23087
777I23133
ROTATING BLADES CAUSE
SERIOUS INJURY OR DEATH
DANGER
TO AVOID SERIOUS INJURY OR DEATH
READ OPERATOR'S MANUAL
TO START
OPERATING MODES
REVERSE CAUTION MODE
1. TURN KEY TO REVERSE CAUTION MODE POSITION.
2. DEPRESS REVERSE PUSH BUTTON. (RED INDICATOR LIGHT “ON”)
WHEN RED LIGHT IS “ON” MACHINE CAN BE OPERATED IN REVERSE
WITH
MOWER BLADES ENGAGED.
IMPORTANT: MOWING IN REVERSE IS NOT RECOMMENDED.
3. AFTER RESUMING FORWARD OPERATION, RETURN KEY TO
“NORMAL MOWING” POSITION.
NOTE:
IN BOTH MODES, WHEN OPERATOR LEAVES SEAT, ENGINE WILL
STOP UNLESS PARKING BRAKE IS SET AND BLADES ARE DISENGAGED.
NORMAL MOWING
YOU MUST DISENGAGE BLADES/PTO,
(POWER TAKE OFF)
BEFORE
T
RAVELING IN REVERSE.
PARKING
BRAKE
CRUISE
CONTROL
LOWER DASH
1. DISENGAGE BLADES/PTO, (POWER TAKE OFF)
2. ENGAGE THE TRACTOR’S PARKING BRAKE.
3. ACTIVATE THE CHOKE CONTROL.
4. TURN KEY TO START ENGINE. AFTER START RELEASE KEY & DEACTIVATE CHOKE
BY PLACING THROTTLE TO
FAST “RABBIT”
POSITION.
PTO
ON
PTO
OFF
DECK
HEIGHT
LO
HI
777S33189
777D13158 (Left Side)
777D13157 (Right Side)
777I23139
CONTACT THE CUB CADE T CA RE N ETWO RK
4 2 8 2
FOR ALL YOUR
SERV ICE N EEDS
1-800-965-4CUB
777X42179
