Cub Cadet LTX 1040 Illustrated Parts Manual

15
Ref.
Part Number Description
1 954-0266A Drive Belt
2 954-04167 Timing Belt
3 710 -1325 Hex Washer Screw, ⁄-20 x 1.625
4 750-04456 Spacer, .260 x .372 x 1.420
5 932-0428A Extension Spring, .50 x 4.35
6 712-04065 Flange Lock Nut, ⁄-16
7 756- 04129B Idler Pulley
8 936-3004 Flat Washer, .406 x .875 x .105
9 750-0807
Spacer, .385 x .625 x .700
10 738-04162A Shoulder Spacer, .8840 x .190
11 983-04524 Brake Assembly
12 710-04484 Hex Washer Screw, ⁄-18 x .750
13
783-06176-0637
Idler Brace Bracket
14 710-0347 Hex Screw, ⁄-16 x 1.75
15 712-0266A Jam Lock Nut, ⁄-16
16 936-0300 Flat Washer, .406 x .875 x .059
17 756-04280 Idler Pulley
18 712- 0229 Push Nut, ⁄
19 750-04446 Spacer, ⁄ x .68 x 1.46
20
783-05802-0637
Tension Bracket
21 710-0520 Hex Screw, ⁄-16 x 1.50
22 710 -1325 Hex Washer, ⁄-20 x 1.625
23 750-0566A Spacer, .260 x .375 x 1.030
24 732-0826A Extension Spring, .865 x 4.68
25 737-04003D Deck Water Nozzle
26 710-0528 Hex Screw, ⁄-18 x 1.25
27 93 6 - 0119 Lock Washer, ⁄
28 917- 04074 Deck Adjustment Gear
29 914-0470 Cotter Pin, ⁄ x 1.25
30 932-0306A Compression Spring, .531 x 1.75
31 747-1116 Deck Handle Rod
32 738-04316A Shoulder Bolt, ⁄-24 x .435 x 1.76
33 783-05627-063 Deck Lift Bracket
34 710-0599 Hex Washer Screw, ⁄-20 x .500
35 731-06291A Belt Cover
Ref.
Part Number Description
36A 918- 04512A Spindle Assembly, Drive
36B 918-04516 Spindle Assembly, Driven
37 711-10 4 4A Belt Guard Pin
38
783-06262-0637
Deck Engage Cable Bracket
39 747-05055 Belt Keeper Rod
40 631-04254 Chute Assembly
41 734-0973 Deck Wheel
42 938-0373 Shoulder Bolt, ⁄-16 x .496 x 1.525
43 710 -3178 Carriage Bolt, ⁄-16 x .75
44 712-04063 Flange Lock Nut, ⁄ x 18
45 942-04217 2-in-1 Blade
46 712- 0417A Flange Nut, ⁄-18
47 710 -3130 Hex Screw, ⁄-16 x 3.25
48 736-0258 Flat Washer, .385 x 1.0 x .135
49 710-3005 Hex Screw, ⁄-16 x 1.25
50 938-0785 Shoulder Spacer, 1.38 x .445 x .36
51 734-04155 Deck Wheel
52 736-0225 Lock Washer, ⁄
53 912- 0641 Hex Nut, M16-1.5
54
683-04492-4021
Deck Assembly
55 756-04372 Pulley (Drive Spindle)
56 750-04724
Spacer, .792 x 1.060 x 1.860 (Drive
Spindle)
57 913-04040A Timing Pulley
58 787- 01520 Timing Pulley Plate
59 710-04065 Screw, ⁄-10 x .625
60 936-0287 Flat Washer, .793 x 1.24 x .06
61 941- 0919 Ball Bearing, .787 x 1.85 x .551
62 750-04936 Spacer, .792 x 1.060 x 1.860
63 937-3000 Drive Lube Fitting
64 619-04199 Spindle Housing
65 938-04292 Spindle Shaft (Drive Spindle)
— 938-04291 Spindle Shaft (Driven Spindle)
66 736-0315 Flat Washer, .760 x 1.50 x .120
67 938-3056 Shoulder Bolt, ⁄-16 x .50 x 2.5
42” U.S. Timed Mowing Deck

Cub Cadet LTX 1040 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	42 inches
Transmission Type	Hydrostatic
Deck Material	Steel
Turning Radius	18 inches
Number of Speeds	Infinite
Cutting Height	1.5 - 4 inches
Number of Blades	2
Front Tire Size	15x6-6
Rear Tire Size	20x8-8
Blade Engagement	Manual
Warranty	3 years limited
Engine Type	Single-cylinder OHV
