27
Ref. Part Number Description
1 KH-20-162-02-S Grass Screen
2
KH-25-086-125-S
Hex Flange Screw
3 KH-25-468-09-S Flat Washer
4 KH-20-146-05-S Fan Mounting Plate
5 KH-20 -157-01-S Fan
6 KH-25-340-02-S Straight Flywheel Key
7 KH-20-025-40-S Flywheel
8 KH-M-548025-S Thd. Frm. Screw, M5 X 0.8 X 25
9 KH-20-154-04-S Wire Clip
10 KH-237878
15 Amp Stator Kit (Inc. KH-25-452-
01-S)
11 KH-25-155-41-S Connector
12 KH-M-545020-S Flg. Thd. Frm. Screw, M5 X .8 X 20
13 KH-41-403-10-S Regulator/Rectier
16 KH-20-584-03-S Ignition Module (CDI Fixed)
17 KH-M-545020-S Flg. Thd. Frm., M5 X .8 X 20
18 759-3336 Spark Plug (Std)
— KH-20-176-16-S Wiring Harness
— KH-25-454-05-S Tie
Kohler SV590-0220 Ignition/Electrical
