Cub Cadet LTX 1040 Illustrated Parts Manual

3
Steering & Front Axle Assembly
Ref.
Part Number Description
1 731-04532B Steering Wheel Cover
2 710-04484 Hex Washer Screw, ⁄-18 x .750
3 936-3004 Flat Washer, .406 x .875 x .105
4 631-04008A Steering Wheel
5 738-04262 Steering Wheel Shaft
6 710-0514 Hex Screw, ⁄-16 x 1.00
7 741-04237A Hex Flange Bearing
8 712-04065 Flange Lock Nut, ⁄-16
9
783-06043-0637
Steering Support Bracket
10 717-1550F Steering Gear
11 736-3084 Flat Washer, .51 x 1.12 x .06
12 717-1554 Steering Gear
13 712-0459 Flange Lock Nut, ⁄-20
14 738-04363 Shoulder Spacer, .385 x 1.25 x .3025
15 710-04095 Hex Screw, ⁄-16 x 1.00
16 711- 0 49 9 8 LH Drag Link
17 711-04999 RH Drag Link
18 712-3004A Flange Lock Nut, ⁄-18
19 912-0240 Jam Nut, ⁄-20
20 923-0448A Lock Joint
21 712-04063 Flange Lock Nut, ⁄-18
22
748-04065-0637
Steering Block
23 710-3180 Hex Screw, ⁄-18 x 1.75
24 912- 0214 Hex Lock Nut, ⁄-24
25 748-04068 Spacer, .71 x .125 x .56
26 712-3083 Hex Lock Nut, ⁄-13
27 719-04413 Axle Pivot Bar
28 750-05041 Spacer, .510 x 1.00 x 1.5075
29 710-04824 Hex Screw, ⁄-13 x 2.5
30
638-04021-0637
RH Axle Assembly
31
638-04027-0637
LH Axle Assembly
32 714-0162 Cotter Pin, ⁄ x 1.25
33 N/A Wheel Assembly (Plastic Flange)
—
634-04405-0499
Rim Assembly
— 734-1731-0901 Tire
— 734-0255 Tubeless Air Valve
— 741-0990B Flange w/ Fitting Bearing
— 741-0516B Flange w/o Fitting Bearing
34 736-04228A Flat Washer, .781 x 1.590
35 731- 05674 Bumper Cap

Cub Cadet LTX 1040 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	42 inches
Transmission Type	Hydrostatic
Deck Material	Steel
Turning Radius	18 inches
Number of Speeds	Infinite
Cutting Height	1.5 - 4 inches
Number of Blades	2
Front Tire Size	15x6-6
Rear Tire Size	20x8-8
Blade Engagement	Manual
Warranty	3 years limited
Engine Type	Single-cylinder OHV
