Page #37 background image
37
Kohler SV590-3222 Crankcase
Ref. Part Number Description
1 N/A Crankcase (Use: Short Block)
4 KH-20-032-01-S Oil Seal
5 KH-20-067-05-S Connecting Assembly Rod
6 KH-20 -874-09-S
Piston W/ Ring Set Kit, 94mm (In-
cludes 7, 8)
7
KH-20-108-04-S
Ring Set (94mm)
8
KH-62-018-04-S
Piston Pin Retainer
9 KH-20-090-01-S Cam Lever Ass. Kit (Includes 10)
10
KH-20-086-06-S
Shd. Thd. Frm. Screw, M6 X 1 X 26
12
KH-20 -123-02-S
Drainback Tube
13
KH-12-154-05
Hitch Pin Clip
14
KH-M-631015
Flat Washer, 6 Mm
15
KH-X-25-102-S
Flat Washer, ⁄
16
KH-20-144- 02-S
Governor Cross Shaft
17
KH-20-393-02-S
Oil Pump Assembly Kit (Includes 11,
18, 19)
18
KH-20-112-02-S
Oil Pump Screw Spacer
19
KH-20-086-13-S
Oil Pump Screw
20
KH-20-144-11-S
Cam Center Shaft Kit (Includes 21)
21
KH-20-468-08-S
Thrust Washer
22
KH-20-010-04-S
Camshaft Assembly Kit (Includes
23-25)
23
KH-20-089-06-S
Acr. Spring
24
KH-20-044-23-S
Acr. Weight
25
KH-20-468-03-S
Thrust -Acr. Washer
26
KH-20-010-04-S
Camshaft Assembly Kit (Includes
27)
27
KH-20-468-03-S
Thrust -Acr. Washer
28
KH-25-139 -57-S
Square Head Pipe Plug, ⁄
