Seat, Fender & Deck Lift
Ref.
Part Number Description
1 757-04085 Medium Back Seat
2
783-06049-0637
Seat Mounting Bracket
3 783-06050 Seat Adjustment Lever
4 732-04563
Compression Spring, .68 x 1.065 x .055
5 938-0296 Shoulder Screw, ⁄-18 x .437 x .268
6 710-04482 Hex Flange Bolt, ⁄-16 x .875
7 710-04484 Hex Washer Screw, ⁄-18 x .750
8 732-04561 Compression Spring, 1.71 x 3.735 x .238
9 712-3004A Flange Lock Nut, ⁄-18
10
783-06088-0637
Seat Pivot Bracket
11 731-06754 Fender Cover. RH
12 710-04484 Hex Washer Screw, ⁄-18 x .750
13 710-0895 Hex Washer Screw, ⁄-15 x .750
14
783-06039-0637
Manual PTO Lift Bracket
15 731- 05515B Fender Cover, LH
16
783-06235-4021
Fender
17 710-0599 Hex Washer Screw, ⁄-20 x .500
18 710-0528 Screw, ⁄-18 x 1.25
19 750-3310 Flange Spacer, .3125 x .4375 x .625
20 735-0690 Grommet, .4375 x .750
21 736-3078 Flat Washer, .344 x 1.0 x .063
22 712- 04063 Flange Lock Nut, ⁄-18
23 946-04618 Deck Engagement Cable
24 714-04040 Bow-Tie Cotter Pin
25 714-3002 Cotter Pin, ⁄ x 1.00
26 747-04944A Deck Lift Rod
27 936- 0179 Flat Washer, ⁄ x 1.25 x .10
Ref.
Part Number Description
28 736 -0317 Bell Washer
29 912- 0206 Hex Nut, ⁄-13
30 712-3083 Hex Lock Nut, ⁄-13
31 738-0138A Shoulder Screw, ⁄-18 x .437 x .470
32 756-04331 Cable Roller Pulley
33 746-0968 Lift Cable
34 712-04063 Flange Lock Nut, ⁄-18
35 714 - 0111 Cotter Pin, ⁄ x 1.0
36
783-04711B-0637
Lift Arm, LH
37 738-04130 Shoulder Bolt, ⁄-16 x .625 x .175
38 712- 04065 Flange Lock Nut, ⁄-16
39 7 20 - 0 4116 Grip
40 732-0932 Extension Spring, .38 x 5.6
41 647-04151 PTO Handle
42 738-04237A Shoulder Screw, #10-32 x .500
43 741-04119 PTO Bearing
44 710-0599 Hex Washer Screw, ⁄-20 x .500
45 716-0106A E-Type Ring
46 941-0225 Hex Flange Bearing
47 746-0968 Lift Cable
48
683-04223-0637
Lift Shift Assembly
49 914-0104 Cotter Pin, .072 x 1.13
50 732-0874 Torsion Spring
51 747-04962A Lift Handle
52 72 0 - 0311 Handle Grip
53 736-0105 Washer, .401 x .870 x .063
54 925-04040 Seat Switch
