9
Ref.
Part Number Description
1 712-0700 Flange Nut
2 954-04208 V-Belt
3 710-1007 Hex Washer Screw, ⁄-16 x 1.500
4 956-04002 Pulley
5 720-04028
Shift Knob
6 647-04035 Shift Lever Assembly
7 756-04325 Idler Pulley
8 710-1026 Hex Washer Screw, ⁄-20 x 1.750
9 710-04823 Bolt, ⁄-18 x 2.75
10 N/A Var. Speed Pulley Ass. w/ Bracket
— 956-04015A Variable Speed Pulley Assembly
— 683-04522 Variable Speed Belt Guide
— 683-04523 Variable Speed Pulley Bracket
— 710-0627 Screw, ⁄-24 x .750
— 710-0778 Screw, ⁄-20 x 1.500
— 718-04261 Bearing Cup
— 736-0362 Flat Washer
— 741-0124 Ball Bearing
11 731-06894 Shift Plate Bearing
12 710-04484 Hex Washer Screw, ⁄-18 x .750
13 914-0209 Internal Cotter Pin
14 747-05109 Shift Rod
15 912- 0431 Flange Lock Nut, ⁄-16
16 723-3018 Joint Ball
17 936-0169 Lock Washer, ⁄
18 712- 0241 Hex Nut, ⁄-24
19 750-04456 Spacer, .260 x .372 x 1.420
20 936-0140 Flat Washer, .385 x .62 x .063
21 747-04957A Foot Pedal Transmission Bypass Rod
22 914 - 0111 Cotter Pin, ⁄ x 1.0
23 747-04959A Idler Adjuster Rod
24 783-06027 Idler Bracket
25 732-04612 Extension Spring, .70 x 12.00
26 954-0467 V-Belt
27 718-04407 Pulley Hub
28 736-04337 Shim Washer, 1.00 x .632 x .010
29 738-0372B Shoulder Spacer, 1.00 x .38 x .38
30 912- 0240 Jam Nut, ⁄-20
31 756-04224 Flat Idler Pulley
32 710 - 3011 Hex Screw, ⁄-16 x 2.25
33 918-04566 Transmatic Drive Assembly
Ref.
Part Number Description
34 731-04604 Sleeve, .758 x .821 x 2.4375
35 712- 04063 Flange Lock Nut, ⁄-18
36 732-0716D Extension Spring, .59 x 4.00
37 732-04616 Extension Spring, .97 x 6.18
38 738-04091A Shoulder Screw, ⁄-18 x .43 x .29
39 936-3008 Flat Washer, .344 x .750 x .120
40 747-04984 Brake Rod
41 783-06132 Shift Bracket
42 732-0525 Spring Shifter Clip
43 710-0227 Hex Washer Screw, #8-18 x .500
44 926-0320 Insulator Nut Plate
45 725-1644 Short Spring Switch
46 914-0104 Cotter Pin, .072 x 1.13
47 710-3025 Hex Screw, ⁄-18 x .625
48 783-04595A Shift Adjustment Bracket
49
634-04639-0499
Rim Assembly, 8.0 x 7.0 x.750
— 934-0255 Tubeless Air Valve
— 734-1730-0901 Tire, 20 x 8 x 8
50 731-2290A Hub Cap
51 710-0627 Hex Lock Screw, ⁄-24 x .750
52 736-0242 Bell Washer, .340 x .872 x .060
53 736-0430 Flat Washer, .350 x 1.59 x .062
54 726-0214 Push Cap, ⁄
55 741-0495 Flange Bearing, .630 x .695 x .60
56 735-0662
Control Pad
57 683-0266 Auto Drive Control Pedal Assembly
58 683-04489 Transmatic Pedal Bracket Assembly
59 783-05914 Pedal Strap Support Bracket
60 712- 04065 Flange Lock Nut, ⁄-16
61 938-0380 Shoulder Bolt, ⁄-16 x .500 x .270
62 741-3065B Hex Flange Bearing
63 748- 04203 Cruise Latch
64 714-04040 Bow-Tie Cotter Pin
65 783-06278 Bracket Reinforcement Plate
66 711-05068 Clevis Pin, ⁄-3.985
67 647-04152 Brake Control Assembly
68 732-04587 Extension Spring, .63 x 4.95
69 710-0604A Hex Washer Screw, ⁄-18 x .625
70 783-05940 Pedal Strap Support Bracket
71
783-06103A-0637
Brake Pedal Bracket
72 735- 04136 Brake Pedal Pad
Drive System
