CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 8-1/(8-2 blank)
CHAPTER 8
PARTS LIST
8-1 INTRODUCTION.
This chapter contains the parts list for replaceable modules
and chassis-mounted components at the operational
maintenance level.
8-2 REPLACEABLE PARTS LISTING.
Table 8-1 lists replaceable modules and chassis-mounted
components for the unit. (See figure FO-5A (CDR-3250) or
FO-5B (CDR-3280) for locations.)
Table 8-1 Replaceable Parts.
Qty Description Part
Number
Remarks Mfr
1 Board, Keypad 260235-1 CCI
1
1 Board, AC Line Filter 260340-1 CCI
1 Board, Serial Remote 260245-1 (Optional) In Digital Module.
Cable below required.
CCI
1 Board, IEEE-488 Remote 260250-1 (Optional) In Digital Module.
Cable below required.
CCI
1 Cable Assy, Fan 260395-1 Includes fan CCI
1 Cable Assy, IEEE-488 to rear panel 260279-1 (Optional) IEEE-488 board rqrd CCI
1 Cable Assy, Serial to rear panel 260386-2 (Optional) Serial board rqrd CCI
4 Handle, Support 222-086 CDR-3250 CCI
4 Handle, Support 2600-4407-7 CDR-3280 CCI
1 Keypad, Rubber Conductive 260006-1 CCI
1 Kit, Dual Rack-Mount 2600-1009-1 CDR-3280 (Two receivers required) CCI
1 Knob, 1/8 shaft 211-119 Power/volume CCI
1 Knob Assy, 1/4 shaft 211-118 Main Adjustment CDR-3280 CCI
1 Knob, 1/4 shaft 260264-1 Main Adjustment CDR-3250 CCI
1 Module, Digital 2600-1105-1 CCI
1 Module, Synthesizer 2600-1106-1 CCI
1 Module, RF Analog (w/preselector) 2600-1107-2 (Standard) CCI
1 Module, RF Analog (w/o preselector) 2600-1107-1 (Optional) CCI
1 Module, Power Supply 260259-1 CCI
1 Module, Display 260018-2 CCI
1 Optical Shaft Encoder Assy 174-005 CCI
1 Power cord, AC 696-012 CCI
1
Cubic Communications, Inc. (FSCM 59532)
