CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 3-21
3-7.4 Scan/Sweep Soft Key Menu.
The following paragraphs detail parameter entry from the sweep/scan soft key menu. To display the sweep/scan soft key menu,
press the NEXT key from the secondary soft key menu.
3-7.4.1 Scan.
NOTE
Before performing a scan function, frequencies and
other parameters to be sampled should be determined
and set into designated memory channels.
Scan is the sequential continuous recall of a sequence of memory channels. The CPU in the receiver uses the data stored in each
channel to select frequency, mode, bandwidth, squelch level, gain, dwell time, bridge time and all other stored parameters to
operate the receiver. The receiver will stop on a frequency (for the current dwell time) when a received signal exceeds the
squelch level set in the channel. If the signal goes away before the dwell timer has timed out, the receiver will continue to scan.
If the dwell timer times out before the signal goes away the receiver continues the scan. If the dwell time is set to zero, the
receiver remains on frequency until the signal falls below the squelch level, and then continues the scan. The operator may
offset the squelch level from the value set in each memory channel before starting the scan.
Scan/Sweep Soft Key Menu.
SCAN SWEEP STEP DWELL BRIDGE
MTR
MNU
NEXT
Press the SCAN key and the following menu appears.
Scan/Sweep - SCAN Soft Key Menu.
FROM TO OFFSET SCAN DONE
MTR
MNU
NEXT
Press the FROM key and the following menu appears.
Scan/Sweep - SCAN - FROM Soft Key Menu.
BKSP ENTER RETURN
MTR
MNU
NEXT
Select the desired starting channel using the keypad or main adjustment knob, and press ENTER. The menu will switch back
to the Scan/Sweep - SCAN menu as shown below.
