CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 3-41
Utility - CONFIG - NEXT MDFLTS Soft Key Menu.
ON OFF CANCEL
MTR
MNU
NEXT
Press the ON or OFF key to select whether default values for BW and AGC are selected when the receive mode is changed. The
display returns to the Primary Menu.
Utility - CONFIG - NEXT Soft Key Menu.
MDFLTS NBIF CANCEL
MTR
MNU
NEXT
Press the NBIF key to adjust the NBIF output center frequency over a limited range of frequencies. The following menu
appears.
Utility - CONFIG - NEXT Soft Key Menu.
INVERT ENTER CANCEL
MTR
MNU
NEXT
Press the INVERT key to select an invert output spectrum or a normal non-invert output spectrum. Adjust the frequency range
by rotating the adjustment knob.
NOTE
Units with a low pass filter output circuit, the frequency range is 8-30 kHz. Units
with a bandpass filter output circuit, the frequency range is 450-460 kHz. These
values are saved in non-volatile memory and needs to be set once unless EEPROM
memory is cleared. When this occurs, the value is set to +455 kHz. (Units with the
low pass filter output circuit, this will produce an output centered at 20 kHz
inverted.
3-7.5.3 Faults.
This function allows review of current or cumulative faults.
Utility Soft Key Menu.
TEST CONFIG FAULTS SYSTEM
MTR
MNU
NEXT
Press FAULTS key to show the current or cumulative faults in the receiver. The following menu appears.
