CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 3-35
Utility - CONFIG - INIT - NEXT Soft Key Menu.
ALL MGC MD CANCEL
MTR
MNU
NEXT
Press the ALL key to reset all non-volatile memory values to default settings.
Utility - CONFIG - INIT - NEXT - ALL Soft Key Menu.
CONT CANCEL
MTR
MNU
NEXT
Press CONT to continue or CANCEL to cancel the function.
Utility - CONFIG - INIT - NEXT - Soft Key Menu.
ALL MGC MD CANCEL
MTR
MNU
NEXT
Press MGC MD to reset the manual gain control to hard or soft. The following menu appears.
Utility - CONFIG - INIT - NEXT - MGC MD Soft Key Menu.
HARD
SOFT DONE
MTR
MNU
NEXT
Press the HARD key to operate in Manual Gain Control Mode (MGC). Press the SOFT key to protect the operator from excess
audio if an incoming signal exceeds the set gain threshold. By selecting the SOFT MGC mode the receiver will have a fixed
gain below the selected signal level and Automatic Gain Control (AGC) above the selected signal level.
3-7.5.2.2 Configuring Receiver Remote Control Operation.
Two basic remote control buses are optionally available; serial
or IEEE-488. Refer to the correct sub-paragraph below for the installed configuration.
3-7.5.2.2.1 Serial Bus.
(If so equipped). To configure the receiver serial bus remote control operation, select the Utility -
CONFIG soft key menu as shown below.
