CDR-3250/80 TECHNICAL MANUAL
3-32 Issue 2.2
Utility - TEST Soft Key Menu.
BITE DSPLY DAC CANCEL
MTR
MNU
NEXT
Press the DSPLY soft key to select the front panel display test. After the test is complete, press any soft key when prompted.
The normal display will be shown with the primary soft key menus.
Utility - TEST Soft Key Menu.
BITE DSPLY DAC CANCEL
MTR
MNU
NEXT
NOTE
When this test is activated, the receiver stops processing incoming signals, and a
fault indication may appear. This is normal.
Press the DAC soft key to select test outputs from the digital-to-analog converter in the digital module. The display will show
what certain test point indications should be. After running the DAC test, power cycle the receiver to restart normal operation.
3-7.5.2 Configuration.
This function configures the receiver by initializing (clearing) non-volatile memory, setting the
remote control parameters, and setting the default settings.
Utility Soft Key Menu.
TEST CONFIG FAULTS SYSTEM
MTR
MNU
NEXT
Press the CONFIG key to select the receiver configuration. The following menu appears.
3-7.5.2.1 Clearing Non-Volatile Memory.
To initialize (clear) non-volatile memory select the Utility - CONFIG soft key
menu as shown below.
Utility - CONFIG Soft Key Menu.
INIT REMOTE PWRDWN ROLOFF CANCEL
MTR
MNU
NEXT
Press INIT to initialize (clear) the non-volatile memory. The following menu appears.
