CDR-3250/80 TECHNICAL MANUAL
3-28 Issue 2.2
Scan/Sweep - SWEEP Soft Key Menu.
FROM TO OFFSET SWEEP DONE
MTR
MNU
NEXT
Press the SWEEP key to start the sweep. The receiver will sweep the band or bands of frequencies between the FROM and TO
channel frequencies using the parameters set in the FROM channel. The following menu appears.
Scan/Sweep - SWEEP - SWEEP Soft Key Menu.
STOP CONT SKIP RETURN
MTR
MNU
NEXT
Press STOP to stop the sweep, CONT to continue the sweep after stopping. Press SKIP to skip an unwanted frequency when
dwelling or bridging on that frequency and to store the frequency in the list of skip frequencies used during sweep. Rotate the
knob to change the sweep rate during the sweep if desired.
3-7.4.3 Step.
When the sweep function is enabled, the receiver will sample a selected frequency, and then "step" to the next
frequency. The step function determines the amount of frequency change between steps.
NOTE
The step setting may also be used as the frequency increment when tuning the receiver
manually with the FREQ soft key menu and the main adjustment knob. This allows
frequency increments other than powers of ten to be assigned to the knob.
Scan/Sweep Soft Key Menu.
SCAN SWEEP STEP DWELL BRIDGE
MTR
MNU
NEXT
Press the STEP key to select the step frequency size for the sweep function. The following menu appears.
STEP Soft Key Menu.
7RATE RATE6 BKSP ENTER CANCEL
MTR
MNU
NEXT
Select the step frequency size with the numeric keys, or main adjustment knob. Pressing the RATE keys to move a bar under
the digits in the display. The bar under the digit indicates the tuning resolution of the main adjustment knob. Press ENTER
when the desired step frequency size is displayed.
