CDR-3250/80 TECHNICAL MANUAL
Table 3-5 Radio Command and Status Messages.
Syntax Reply Description
3-54 Issue 2.2
EEPCLR
Clear the entire contents of the receiver's non-volatile memory. All user
selected configuration items will be set to the original factory values.
These values are:
All 250 memory channels to default parameters.
Front panel parameters stored at power down to default parameters
Clear all frequencies from sweep skip table
Soft key assignments for bandwidth and AGC
Mode defaults enabled
Mode defaults reset to original values
Front panel Local/Remote selection to Remote
!Receiver bus address to 000
!Bus type to RS-232 (serial only)
!Baud rate to 19,200 bps (serial only)
!Line Parameters to 8 bits, no parity, 1 stop bit (serial only)
!Bus sharing On (serial only)
SSB Roll off to 400 Hz
Saving of parameters on power down disabled
Display intensity to 100%
Keypad clicks and beeps enabled
Soft key menus shown by default
Reference mode to Automatic
NOTE: Execute this command with extreme caution! When the receiver
changes to the default interface parameters listed above with dots (!),
the remote controller will need to change to these values also unless they
are already set. Never use this command when more than one receiver is
connected to the bus as they will all be set to address 000. Receiver local
operation may also be affected by this command.
F12345678
Change receiver operating Frequency. Digits 1 through 8 represent the
eight digits of the receiver operating frequency with 1 representing the
most significant (10 MHz digit) and 8 representing the least significant (1
Hz). (Range: 0 to 30 MHz or F00000000 through F30000000)
F?
Request current frequency.
(cont)
