Culligan 9" - The Culligan Process

3
01021076
Culligan High Efciency Softener—Upow Regeneration
Model 9" Model 10" Model
Control Valve 1” Reinforced Thermoplastic with HE Circuit Board
Overall Conditioner Height 56 in 62 in
Media Tank Design Quadra-Hull™
Media Tank Dimensions (Dia x Ht) 9 x 48 in 10 x 54 in
Salt Storage Tank Dimensions (Dia x Ht) 16" x 43" or 18" x 43"
Exchange Media, Type and Quantity Cullex® Media, 1.0 ft
3
Cullex Media, 1.5 ft
3
Underbedding, Type and Quantity Cullsan® Underbedding, 12 lb Cullsan Underbedding, 15 lb
Exchange Capacity @ Salt Dosage Per Recharge 9,792 gr @ 2.0 lb 30,081 gr @ 6.0 lb
17,366 gr @ 4.0 lb 47,726 gr @ 12.0 lb
27,306 gr @ 8.0 lb 54,975 gr @ 18.0 lb
Efficiency rated dosage
1
4,896 gr/lb @ 2 lb salt dosage 5,014 gr/lb @ 6 lb salt dosage
Proportional Brining Efficiency Rating
2
5,760 gr/lb @ 2 lb salt dosage 5,898 gr/lb @ 6 lb salt dosage
Freeboard to Media
3
14.5 in 14.5 in
Freeboard to Underbedding
4
44.5 in 47.5 in
Salt Storage Capacity 250 lb or 375 lb
Rated Service Flow @ Pressure Drop 9.0 gpm @ 11 psi 9.4 gpm @ 12 psi
Auxiliary Flow Rate
5
10.8 gpm @ 15 psi 11.0 gpm @ 15 psi
Total Hardness, Maximum 30 gpg
Total Iron, Maximum 2 ppm
Hardness to Iron Ratio, minimum 8 gpg to 1 ppm
Operating Pressure 20-125 psi (138–862 kPa)
Operating Pressure (Canada) 20-90 psi (138–621 kPa)
Operating Temperature 33-120°F (0–49°C)
Electrical Requirements 24V/60 Hz
Electrical Power Consumption, Min/Max 8.4 watts/21.6 watts
Drain Flow, Maximum
6
2.2 gpm 2.3 gpm
Recharge Time, Average
7
Recharge Water 68 minutes 57 minutes
Consumption, Average
7
(Evaluated by WQA) 33 gallons 35 gallons
Consumption, Average
8
(Not evaluated by WQA) 25.5 gallons 27.5 gallons
1
The efficiency rated dosage is only valid at the stated salt dosage and 5-minute backwash. It is efficiency rated according to NSF/ANSI 44.
2
The Proportional Brining Efficiency Rating assumes a 20 percent reserve capacity at the time of regeneration that is typical of what the manufacturer expects
under real-world operation. Proportional brining is not measured by NSF/ANSI 44, and so this cliam is not, and can not, be rated to NSF/ANSI 44.
3
Measured from top of media to top surface of tank threads. (backwashed and drained).
4
Measured from top of underbedding to top surface of tank threads.
5
Auxiliary flow rates do not represent the maximum service flow rate used for determining the softener’s rated capacity and efficiency and that continuous
operation at these flow rates greater than the maximum service flow rate may affect capacity and efficiency performances.
6
Backwash at 35 psi (830 kPa).
7
5 minute backwash, 2 lb. 9" model, 6 lb. 10" model. These values have been tested and certified by WQA.
8
2 minute backwash, 2 lb. 9” model, 6 lb. 10” model. These values are based on the manufacturer recommended backwash time.
