Culligan HE Municipal Water Softener
9" Model 10" Model 12" Model 14" Model
Control Valve 1”, 5-cycle Reinforced Thermoplastic with Global Electronic (GBE) Circuit Board
Overall Conditioner Height 54 in 60 in 58 in 71 in
Media Tank Design Quadra-Hull™
Media Tank Dimensions (Dia
x Ht)
9 x 48 in 10 x 54 in 12 x 52 in 14 x 65 in
Salt Storage Tank Dimensions
(Dia x Ht)
16 x 43 in or
18 x 43 in
16 x 43 in
or 18 x 43 in
18 x 43 in 24 x 42 in
Exchange Media, Type and
Quantity
Cullex
®
Media,
0.8 ft
3
Cullex
®
Media,
1.0 ft
3
Cullex
®
Media,
1.5 ft
3
Cullex
®
Media,
2.3 ft
3
Carbon Media, Quantity 6 lbs 8 lbs 12 lbs 18 lbs
Underbedding, Type and
Quantity
Cullsan
®
Underbedding, 12 lb
Cullsan
®
Underbedding, 15 lb
Cullsan
®
Underbedding, 20 lb
Cullsan
®
Underbedding, 25 lb
Exchange Capacity @ Salt
Dosage Per Recharge
17,119 gr @ 4.0 lb 21,399 gr @ 5.0 lb 29,062 gr @ 7.0 lb 39,118 gr @ 9.0 lb
25,232 gr @ 8.0 lb 31,540 gr @ 10.0 lb 43,990 gr @ 18.0 lb 59,297 gr @ 18.0 lb
27,806 gr @ 12.0 lb 34,758 gr @ 15.0 lb 49,343 gr @ 30.0 lb 71,448 gr @ 28.0 lb
Efficiency rated dosage
1
4,280 gr/lb @
4 lb salt dosage
4,280 gr/lb @
5 lb salt dosage
4,152 gr/lb @
7 lb salt dosage
4,346 gr/lb @
9 lb salt dosage
Chlorine Taste and Odor
Capacity
300,000 gallons 339,000 gallons 621,000 gallons 935,000 gallons
Freeboard to Media
2
15.75 in 19.5 in 17.31 in 25.89 in
Freeboard to Underbedding
3
44.5 in 47.5 in 46 in 59 in
Salt Storage Capacity 250 lb or 375 lb 375 lb 650 lb
Rated Service Flow @
Pressure Drop
9.0 gpm @ 12 psi 9.4 gpm @ 11 psi 10.0 gpm @ 11 psi 10.6 gpm @ 11 psi
Total Hardness, Maximum 15 gpg
Total Iron, Maximum 0 ppm
Color Less Than 1
Turbidity Less Than 5 NTU
TOC Less Than 0.5 PPM
Operating Pressure 20-125 psi (138–862 kPa)
Operating Pressure (Canada) 20-90 psi (138–621 kPa)
Operating Temperature 33-120°F (0–49°C)
Electrical Requirements 24V/60 Hz
Electrical Power Consumption,
Min/Max
8.4 Watts/21.6 Watts
Drain Flow, Maximum
4
2.6 gpm 2.6 gpm 3.2 gpm 6.2 gpm
Recharge Time, Average
5
Recharge Water
78 min 67 min 62 min 76 min
Consumption, Average
5
70 gal 70 gal 97 gal 162 gal
1
The efficiency rated dosage is only valid at the stated salt dosage and is efficiency rated according to NSF/ANSI 44.
2
Measured from top of media to top surface of tank threads. (backwashed and drained).
3
Measured from top of underbedding to top surface of tank threads.
4
Backwash at 120 psi (830 kPa).
5
10 minute backwash, 4 lb. 9” model, 5 lb. 10” model, 7 lb. 12” model, or 9 lb. 14” model.
