Culligan CSM Series User Manual

Suggested Preventative Maintenance 63
Cat. No. 01016370
PROBLEM OR SYMPTOM CHECK PROCEDURE CAUSE
Pilot Does Not Pressurize or Vent
Valve Ports Properly
Check Screen on Pilot Strainer Clogged Screen prevents control
pressure from reaching pilot valve
(and solenoid valves if applicable).
1. Manually rotate the pilot (in the
proper direction) as required until
the valve(s) in question should be
closed. (Refer to the valve flow di-
agrams on page 66). Remove
the control tubing from the valve
port cover and check for water
from the tube.
2. Manually return the pilot to the H
(Home) position.
If water flows out of the control tubing,
check the fitting in the valve port cover
for an obstruction.If water does not
flow out of the control tubing, check
the control tubing and fitting in the pi-
lot body for an obstruction.
1. While in the H (Home) position
and not in stand by (multiple units
with blocking solenoids), remove
the control tubing from the valve
port covers 1#1 and #4.
2. Reconnect the tubing removed in
step #1. Manually rotate the pilot
(in the proper direction) to the #1
position. Remove the control tub-
ing from valve port covers #2 and
#5. Also remove the control tub-
ing from port #17 on units with the
B-brunermatic bypass valve oper-
ated by the pilot.
3. Reconnect the tubing removed in
step #2. Manually advance the pi-
lot (in the proper direction) to the
#2 position. Remove the control
tubing from valve port cover #6.
4. Reconnect the tubing removed in
step #3. Manually advance the pi-
lot (in the proper direction) to the
H (Home) position).
1a. If water flows from the control tub-
ing, perform service on the pilot valve
(and/or blocking solenoid valve(s) if
used).
1b. If water flows from the valve port
cover(s) perform service on the dia-
phragm valve assembly(ies).
2 & 3a. If water flow from the control
tubing, perform service on the pilot
valve.
2 & 3b. If water flows from the valve
port cover(s) perform service on the
diaphragm valve assembly(ies).
Softener Tank Does Not Remain in
Stand By Mode or Will Not Provide
Water Thru the Outlet of the Bruner-
matic Valve When in Service (Only
systems using blocking valves)
Verify operation of the solenoid valve
operation port #4 of the Brunermatic
valve.
Solenoid valve may not be prop-
erly wired or water hardness scale
build-up inside solenoid is causing
malfunction.
