44 Culligan® Series E2 Plus Reverse Osmosis
44 Cat. No. 01023094
Concentrate Piping Sub-Assembly, 220V/ 50 Hz, International
Figure 26. E2 Plus concentrate piping sub-assembly.
Item Part No. Description Qty.
— 01022958 Piping Assembly E2 Plus Concentrate
1 01021539 Valve,Needle,1/2" Brass 2
2 — Fitting,Male Connector,1/2Tx1/2NPTE,PI 4
3 — Fitting,Stem Elbow,1/2Tx1/2Stem,PI 2
4 — Fitting,Union Tee,1/2T,PI 1
5 00901801 Tubing,1/2",PE,Natural —
