Culligan E2 Plus Series - Unit Configurations

4 Culligan® Series E2 Plus Reverse Osmosis
4 Cat. No. 01023094
Unit Configurations
An E2-6 Plus unit is pictured in Figure 1 and Figure 2. Width of membrane rack varies with model. See “E2 Plus RO Parts
Diagrams and Lists” on page 28 for a list of component part numbers.
Pump
Water and Recirculation
Control Valves
Feed and Product
Flow Meters
Pump Pressure
Gauge
Filter
Arrays
Front Panel
Assembly
Prefilter
Throttling
Valve
Filter
Arrays
Figure 1. E2 Plus RO front view.
Motor
Pump
Inlet
Prefilter
Figure 2. E2 Plus RO rear view.
