If inlet water pressure is greater than 100 psi, a pressure regulator must be
installed prior to the water dispenser connection (not provided).
! !
Flush the new lters as per the manufacturers recommendation before
installing them into the unit!
! !
7
ADDING FILTRATION: EXTERNAL
1. The white tube must be connected to the lter
system inlet.
3. Mount the lter to the condenser coils on the back of
the unit high enough that the lter can be removed.
Culligan oers options for ltration to be added to your cooler. Contact Culligan for details.
Large, higher capacity lters will have to be mounted to the outside of the cooler.
2. The blue tube must be connected to the lter system
outlet.
4. Insert the ltered water out line (blue) into the Water
Line In bulkhead tting on the back of the unit.
INLET
OUTLET
